Hdfury Integral 2
This Hdfury Integral 2 unique HDMI2.0b and HDCP2.2 device supports true full 4K60 4:4:4 600MHz 18Gbps bandwidth signals. It will allow you to solve any HDCP error, Split or Matrix any SD/HD/FHD/UHD/HDR/DV or PC signals up to 600MHz, scale up or scale down between FHD and UHD on any channel individually, display relevant information on OSD, select between multiple edid banks, Inject Infoframe and more. Control can be completed with IR codes, through slide switch or push buttons on the unit, via a wired USB connection to a Windows PC, via RS232 (MAC/WIN/Linux) or through wireless Bluetooth connection with any Smartphone or Tablet running Android or iOS. (GoBlue mandatory for iOS/Android APP support)
HDfury Integral 2 is capable of converting HDCP, FHD<>UHD Resolution, Chroma, Color Depth, Color Space and more in order to individually feed any of the connected sinks at their best capabilities. GUARANTEED!
User can pass thru Dolby Vision or HDR from Source to TV while sending Dolby Atmos or any sound format to a non DV or HDR capable AVR.
Featuring a true 2×2 18Gbps HDMI matrix/splitter/switcher/scaler/converter/audio de-embedder, HDfury Integral 2 can also act as an Infoframe and HDR metadata Injector and Extractor, HDCP Doctor, CEC Commander, HDMI Doctor, EDID manager and more…
It supports any HDMI, any HDCP and any HDR up to HDR10+, HLG or Dolby Vision, including LLDV.
with any sound format in existence today.
It provides full EDID management for an optimal handling of today’s wide variety of sources and displays and comes with OSD, IR, RS232 and stereo or optical audio output for ARC up to Atmos®, DD+®, Dolby® 7.1, DTS® and LPCM for capable sink.
Instantly get and feel the HDMI supervisor power through OSD, Windows GUI, RS232, iOS/Android APP (with GoBlue) and more…Note that it have the best 18Gbps signal integrity ever seen for a 5v device, thus ensuring seamless integration even with marginal cables that would otherwise not work with others devices for high bandwidth signals.
If you ever saw the following statement: “this TV does not support HDCP 2.2. Make sure you have HDCP 2.2 capable TV” or a similar HDCP error message, make sure you never see it again with HDfury Integral 2!
Hdfury Integral 2 Specs.
|HDMI revision:||HDMI 2.0b (Level A) 600Mcsc – 18Gbps|
|Max Resolution:||4K60 4:4:4 8b, 4K60 4:2:2 12b, 4K120 4:2:0 8b or 8K30 4:2:0 8b|
|I/O:||2 HDMI In, 2 HDMI Out, IR, RS232, USB, Analog Jack, Optical Out.|
|Upscale port:||FHD 1080p to UHD 2160p & 2K/DCI to 4K/DCI|
|Downscale port:||UHD 2160p to FHD 1080p & 4K/DCI to 2K/DCI|
|Signal Conversion:||Resolution, Chroma Subsampling, Color Space, Color Depth, HDCP|
|HDCP Conversion:||Any HDCP to any HDCP with CST1 support|
|Operating Modes:||18Gbps Scaler, Switcher, Splitter & Matrix with CEC, ARC and EDID management|
|Special Modes:||CEC Command, HTPC, Disable or inject HDR, HDMI Doctor and JVC Macro.|
|EDID Modes:||10 EDID Flags, 100 EDID Banks (10 custom)|
|Infoframe Modes:||Capture, edit, block or replace HDR metadata, AVI & VSIF. |
Read SPD, Audio, HDMI Vendor, HDMI
|Control Modes:||IR, Windows GUI, RS232 for Linux/MAC/Win, Android/iOS with GoBlue|
|On Screen Display:||Editable with custom text and mask. (cover TV channel logo)|
|Dimension:||3.9″L x 2.4″W x 0.8″H – in CM: 10 x 6 x 3|
|Weight:||130g – 0.3 LBS|
|Other info:||Input Lag <1ms (nanoseconds count)|
Hdfury Integral 2 is a State of the art HDMI central for FHD source or sink in UHD/HDR setup or the other way around. Comes with OSD, huge scaling power and toolkit for researcher, content creator or advanced user.
Support any video and/or audio signal in existence today including DV, HLG, HDR10+, DTS:X, ATMOS and more…
Integral2 allows any source (Blu-ray, UHD Blu-ray, media players, satellite receiver, game consoles, PCs, etc.) to be shown on any of the connected displays and any sources HDMI audio to be played on any AVR.
With built-in scalers you don’t have to miss any 4K HDR signal because of older legacy equipment in the signal path.
